BETTER MCM Baker style Float Valves Model G Flapper Type Full Open Valve, GA Differential Pressure Monitoring Valve, Repair Kits
| Place of Origin | China |
|---|---|
| Brand Name | BETTER |
| Certification | API 7K, 6A, 8C, ISO |
| Model Number | BAKER SPD |
| Minimum Order Quantity | 1 SET |
| Price | USD300.00 PER SET |
| Packaging Details | Carton, Plywood Case |
| Delivery Time | 7-10 days |
| Payment Terms | T/T, West Union |
| Supply Ability | Fast Delivery, Plenty in Stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| TYPE | F, G, FA, GA | Material | Alloy Steel |
|---|---|---|---|
| Color | Blue, Yellow, Red, Black, Etc |
Product Description
BETTER provides Float Valves, Repair Kits, Baffle Plates and Puller Assembly Tools, including H2S and high temperature service condition. This Drill Pipe Float Valve provides added blowout protection at the bottom of the drillstring, prevent flowback when joints are added, and keep cuttings out of drill pipes to prevent bit plugging while making connections.
Feature
- All BETTER Float Valves are manufactured with alloy steel integral.
- All Flappers are investment cast and then case hardened for wear resistance.
- Elastomers available Buna-N/NBR (Standard), /FKM (Hi-Temp), HNBR (H2S) for optional.
- All BETTER Float Valves, baffle plates, and valve pullers are interchangeable with the Baker® Style Model F/FA, and Baker® Style Model G/GA Float Valves.
- Heat Treatment: Carburize at 1500-1550°F to .005/.010 depth with hardness 58 HRC Min.
- Surface treatment: Xylan fluoropolymer coating with depth 0.25-0.30mm or Nicked Plated.
- Standard API NRV
- Color Blue or Black, or customized.
Specification
| Valve Size |
D Diameter of Valve |
R(D+1/32) Diameter of Recess for Valve |
L Length of Valve |
T* Diameter of Recess for Baffle Plate |
ID of Valve | |
| Model F | Model G | |||||
| in. | in. | in. | in. | in. | in. | |
| 1R | 1-21/32 | 1-11/16 | 5-7/8 | 1-5/16 | 1 | N/A |
| 1F-2R | 1-29/32 | 1-15/16 | 6-1/4 | 1-1/2 | 1-1/4 | 1 |
| 2F-3R | 2-13/32 | 2-7/16 | 6-1/2 | 1-29/32 | 1-9/16 | 1-1/4 |
| 3F | 2-13/16 | 2-27/32 | 10 | 2-7/16 | 1-7/8 | 1-5/8 |
| 3-1/2 IF | 3-1/8 | 3-5/32 | 2-11/16 | |||
| 4R | 3-15/32 | 3-1/2 | 8-5/16 | 2-15/16 | 2-5/16 | 1-31/32 |
| 4F | 3-21/32 | 3-11/16 | 12 | 3-1/4 | 2-1/2 | 2-3/16 |
| 5R | 3-7/8 | 3-29/32 | 9-3/4 | 3-3/8 | 2-3/4 | 2-1/4 |
| 5F-6R | 4-25/32 | 4-13/16 | 11-3/4 | 4-9/32 | 3-1/4 | 2-7/8 |
| 6F | 5-11/16 | 5-23/32 | 14-5/8 | 5-3/16 | 4-1/8 | N/A |
Model G Model GA
| SIZE | Complete Assembly P/N | Metal Repair-Kit P/N |
Rubber Repair Kit P/N |
Complete Assembly PIN |
Metal Repair-Kit P/N |
Rubber Repair Kt P/N |
| 2F 3R |
M-152-432 480152432 |
M-013-200 016013200 |
M-013-800 016013800 |
M-162-432 480162432 |
M-135-000 017135000 |
M-013-800 016013800 |
| 3F | M-153-400 480153400 |
M-013-300 016013300 |
M-013-900 016013900 |
M-163-400 480163400 |
M-136-700 017136700 |
M-013-900 016013900 |
| 31/2 IF |
M-153-600 480153600 |
M-013-300 016013300 |
M-982-000 051982000 |
M-163-600 480163600 |
M-136-700 017136700 |
M-982-000 051982000 |
| 4R | M-154-200 480154200 |
M-013-400 016013400 |
M-014-000 016014000 |
M-164-200 480164200 |
M-116-000 017116000 |
M-014-000 016014000 |
| 4F | M-154-400 480154400 |
M-013-500 016013500 |
M-014-100 016014100 |
M-164-400 480164400 |
M-136-800 017136800 |
M-014-100 016014100 |
| 5R | M-155-200 480155200 |
M-013-600 016013600 |
M-014-200 016014200 |
M-165-200 480165200 |
M-136-900 017136900 |
M-014-200 016014200 |
| 5F 6R |
M-155-462 480155462 |
M-013-700 016013700 |
M-014-300 016014300 |
M-165-462 480165462 |
M-134-200 017134200 |
M-014-300 016014300 |
| Description | 2F 3R | 3F | 31/2 IF | 4R | 4F | 5R | 5F 6R |
| CAGE | M-44231 | M-46278 | M-19658 | M-44195 | M-46272 | M-47718 | M-44238 |
| SIDE SEAL | M-03939 | M-02015 | M-03986 | M-03940 | M-01908 | M-03941 | M-01958 |
| SPRING | M-44235 | M-46231 | M-46231 | M-44210 | M-46226 | M-46226 | M-44240 |
| SEAL RETAINING RING |
M-44233 | M-46287 | M-46287 | M-43587 | M-46277 | M-47722 | M-44237 |
| SEAL | M-43574 | M-46243 | M-46243 | M-41303 | M-45340 | M-47721 | M-43597 |
| FLAPPER-VALVE | M-27065 | M-27054 | M-27054 | M-27064 | M-27052 | M-27053 | M-27066 |
| BUMPER(LARGE) | M-44243 | M-44243 | M-44243 | M-44213 | M-44213 | M-44213 | M-44213 |
| PIN | M-43575 | M-43575 | M-43575 | M-46397 | M-46397 | M-47723 | M-43595 |
| SHOCK ABSORBER | M-43573 | M-46242 | M-19659 | M-42709 | M-45339 | M-47720 | M-43596 |
| BUMPER(SMALL) | M-44214 | M-44214 | M-44214 | M-44214 | M-44214 | M-44214 | M-44214 |
| SPRING ASSY. | M-47763 | M-47764 | M-47764 | M-47760 | M-47761 | M-47761 | M-47762 |
