BETTER FET Baker style Float Valves Model G Flapper Type Full Open Valve, GA Differential Pressure Monitoring Valve, Repair Kits
| Place of Origin | China |
|---|---|
| Brand Name | BETTER |
| Certification | API 7K, 6A, 8C, ISO |
| Model Number | BAKER SPD |
| Minimum Order Quantity | 1 SET |
| Price | USD300.00 PER SET |
| Packaging Details | Carton, Plywood Case |
| Delivery Time | 7-10 days |
| Payment Terms | T/T, West Union |
| Supply Ability | Fast Delivery, Plenty in Stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| TYPE | F, G, FA, GA | Material | Alloy Steel |
|---|---|---|---|
| Color | Blue, Yellow, Red, Black, Etc |
Product Description
BETTER provides Float Valves, Repair Kits, Baffle Plates and Puller Assembly Tools, including H2S and high temperature service condition. This Drill Pipe Float Valve provides added blowout protection at the bottom of the drillstring, prevent flowback when joints are added, and keep cuttings out of drill pipes to prevent bit plugging while making connections.
Feature
- All BETTER Float Valves are manufactured with alloy steel integral.
- All Flappers are investment cast and then case hardened for wear resistance.
- Elastomers available Buna-N/NBR (Standard), /FKM (Hi-Temp), HNBR (H2S) for optional.
- All BETTER Float Valves, baffle plates, and valve pullers are interchangeable with the Baker® Style Model F/FA, and Baker® Style Model G/GA Float Valves.
- Heat Treatment: Carburize at 1500-1550°F to .005/.010 depth with hardness 58 HRC Min.
- Surface treatment: Xylan fluoropolymer coating with depth 0.25-0.30mm or Nicked Plated.
- Standard API NRV
- Color Blue or Black, or customized.
Specification
| Valve Size |
D Diameter of Valve |
R(D+1/32) Diameter of Recess for Valve |
L Length of Valve |
T* Diameter of Recess for Baffle Plate |
ID of Valve | |
| Model F | Model G | |||||
| in. | in. | in. | in. | in. | in. | |
| 1R | 1-21/32 | 1-11/16 | 5-7/8 | 1-5/16 | 1 | N/A |
| 1F-2R | 1-29/32 | 1-15/16 | 6-1/4 | 1-1/2 | 1-1/4 | 1 |
| 2F-3R | 2-13/32 | 2-7/16 | 6-1/2 | 1-29/32 | 1-9/16 | 1-1/4 |
| 3F | 2-13/16 | 2-27/32 | 10 | 2-7/16 | 1-7/8 | 1-5/8 |
| 3-1/2 IF | 3-1/8 | 3-5/32 | 2-11/16 | |||
| 4R | 3-15/32 | 3-1/2 | 8-5/16 | 2-15/16 | 2-5/16 | 1-31/32 |
| 4F | 3-21/32 | 3-11/16 | 12 | 3-1/4 | 2-1/2 | 2-3/16 |
| 5R | 3-7/8 | 3-29/32 | 9-3/4 | 3-3/8 | 2-3/4 | 2-1/4 |
| 5F-6R | 4-25/32 | 4-13/16 | 11-3/4 | 4-9/32 | 3-1/4 | 2-7/8 |
| 6F | 5-11/16 | 5-23/32 | 14-5/8 | 5-3/16 | 4-1/8 | N/A |
MODEL G AND GA DPFV
Flappers for Model G/GA are made of normalized, carbonized, quenched, and tempered low alloy steel to resist wear and erosion. The flapper valve opens fully during circulation providing an unrestricted bore through the valve thereby effectively prolonging the life of the valve and drill collar as there is no diversion of fluid against the drill collar ID.
P/N:48015 /48016
Model G Flapper Type Full Open Valve Full Flow
P/N: 480151422, 480152432, 480153400, 480153600, 480154200, 480154400, 480155200, 480155462
480311422, 480312432, 480313400, 480313600, 480314200, 480314400, 480315200, 480315462.
Model GA Differential Pressure Monitoring Valve Full Flow Ported Flapper Type with Carbide Orifice
P/N: 480161422, 480162432, 480163400, 480163600, 480164200, 480164400, 480165200, 480165462
480261422, 480262432, 480263400, 480263600, 480264200, 480264400, 480265200, 480265462
Repair Kits for all Styles of Model G and GA DPFV: pring Assemblies/Hinge Pins/Seal Retaining Ring/Flapper Valve/side seals/valve seals/shock absorber/seal retaining ring
Metal Repair Kit: P/N: 051988400, 016013200, 016013300, 052070200, 016013400, 016013500, 016013600, 016013700
Rubber Repair Kit: P/N:051988300, 016013800, 016013900, 051982000, 016014000, 016014100, 016014200, 016014300
