BETTER Halliburton Style Plug Valve bottom Entry Plug Valve Low Torque 1",2",3"
| Place of Origin | China |
|---|---|
| Brand Name | BETTER |
| Certification | API 7K, 6A, 8C, ISO |
| Model Number | Halliburton |
| Minimum Order Quantity | 1 SET |
| Price | OFFER |
| Packaging Details | Carton, Plywood Case |
| Delivery Time | 7-10 days |
| Payment Terms | T/T, West Union |
| Supply Ability | Fast Delivery, Plenty in Stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Alloy | Technics | Forged |
|---|---|---|---|
| Type | Plug | Connection | Male |
| Shape | Equal | Head Code | Hexagon |
Product Description
BETTER's plug valve body are forged by the high quality alloy steel. All processes including forging, machining, heat treatment and pressure test are strictly controlled and fully traceable in according to API 6A, API 16C and Q1, as well as NACE-MR-01-75(sour gas service)full packages of material Test Report can be sent with consignment upon client's request.
We can supply the low torque plug valve size ranging from 1" to 3" and can be handle up to 15000psi for either standard service or sour gas service.
BETTER's Halliburton style Plug Valves and spare parts 100% interchangeable with Halliburton brand.
Service : standard and sour Bore (inches)
- standard service: 1", 2", 3"
- sour service: 1", 2", 3"
| ITEM | DESCRIPTION | PART NUMBER |
| 1 | 1” Plug valve low torque 1x1 male x female fig.1502 standard service- bar nut operated | 1PV711MFRAB |
| 2 | 1” Plug valve low torque 1x2 male x female fig.1502 standard service- bar nut operated | 1PV722MFRAB |
| 3 | 2” Plug valve low torque male x female fig.1502 standard service- bar nut operated | 2PV722MFRAN |
| 4 | 3” Plug valve low torque heavy duty male x female fig.1502 standard service- bar nut operated | 3PV733MFRAJ |
| 5 | 2” PLUG VALVE LOW TORQUE REPAIR KIT | |
| 6 | 2” PLUG VAVLE LOW TORQUE SEAL KIT |
| Name | 1"×2"plug valve | 2"×2"plug valve | 3"×3"plug valve | ||||||
| Qty. | 105Mpa | 70Mpa | 42Mpa | 105Mpa | 70Mpa | 42Mpa | 105Mpa | 70Mpa | 42Mpa |
| 15000psi | 10000psi | 6000psi | 15000psi | 10000psi | 6000psi | 15000psi | 10000psi | 6000psi | |
| Side segment | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Seal segment | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Inner seal and Outer seal | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Plug | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Lock nut, Hex | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| O-ring for body cap | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| O-ring for plug | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Nylon backup ring | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Grease Retainer Ring | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Grease fitting | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
Feature
1. Forged body by alloy steel
2. Low torque operation
3. Flanged, threaded connection is available
4. Fast, simple field repair
Related Products
We can also supply WECO ULT Plug Valve and DR style plug valve. And other check valve, swivel joint, wing unions, fittings, pup joints for flow control.
