BETTER MSI Style Plug Valve bottom Entry Plug Valve Low Torque 2"
| Place of Origin | China |
|---|---|
| Brand Name | BETTER |
| Certification | API 7K, 6A, 8C, ISO |
| Model Number | MSI |
| Minimum Order Quantity | 1 SET |
| Price | OFFER |
| Packaging Details | Carton, Plywood Case |
| Delivery Time | 7-10 days |
| Payment Terms | T/T, West Union |
| Supply Ability | Fast Delivery, Plenty in Stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Alloy | Technics | Forged |
|---|---|---|---|
| Type | Plug | Connection | Male |
| Shape | Equal | Head Code | Hexagon |
Product Description
BETTER's plug valve body are forged by the high quality alloy steel. All processes including forging, machining, heat treatment and pressure test are strictly controlled and fully traceable in according to API 6A, API 16C and Q1, as well as NACE-MR-01-75(sour gas service)full packages of material Test Report can be sent with consignment upon client's request.
We can supply the low torque plug valve size ranging from 1" to 3" and can be handle up to 15000psi for either standard service or sour gas service.
Specification
BETTER can provide the type of bottom entry plug valve, interchangeable with HALLIBURTON/MSI/TSI/NOV ANSON/CSCC. These plug valves can be manual, gear, or actuated operation.
| Part Number | Description | Actuation | WP (PSI) |
| 316A-2S2U-M-3 | VALVE-316, 2″ X 2″ 1502 STD 10.56″ OAL | 15000 | |
| 316A-2H2U-M-1 | VALVE-316, 2″ X 2″ 1502 H2S 10.56″ OAL | 10000 | |
| 316A-2S2U-M-6 | VALVE-316, 2″ X 2″ 1502 STD 13.88″ OAL | 15000 | |
| 316A-2H2U-M-6 | VALVE-316, 2″ X 2″ 1502 H2S 13.88″ OAL | 10000 |
Feature
* Forged body by alloy steel
* Low torque operation
* Flanged, threaded connection is available
* Fast, simple field repair
Related Products
We can also supply WECO ULT Plug Valve and DR style plug valve. And other check valve, swivel joint, wing unions, fittings, pup joints for flow control.
