BETTER Demco DM Type Mud Gate Valve Equiv to MUDKING style 2", 4"×3", 5"×4”

  • BETTER Demco DM Type Mud Gate Valve Equiv to MUDKING style 2", 4"×3", 5"×4”
  • BETTER Demco DM Type Mud Gate Valve Equiv to MUDKING style 2", 4"×3", 5"×4”
  • BETTER Demco DM Type Mud Gate Valve Equiv to MUDKING style 2", 4"×3", 5"×4”
Place of Origin China
Brand Name BETTER
Certification API 7K, 6A, 8C, ISO
Model Number 2", 3",4" , XXH BW, STD
Minimum Order Quantity 1 SET
Price USD 500.00 PER SET
Packaging Details Carton, Plywood Case
Delivery Time 7-10 days
Payment Terms T/T, West Union
Supply Ability Fast Delivery, Plenty in Stock

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Standard Or Nonstandard Standard Structure Gate
Pressure High Pressure Power Manual
Material Alloy Temperature Of Media Normal Temperature
Media Base
Leave a Message
Product Description

BETTER Mud Gate Valve is equivalent to DEMCO model DM series.Our DEMCO DM style gate valves, the good quality gate valve in the oil and gas drilling market, are specifically engineered for the rigorous requirements of oilfield applications.

Products show

BETTER Demco DM Type Mud Gate Valve Equiv to MUDKING style 2", 4"×3", 5"×4” 0

Specifications


BETTER Demco DM Type Mud Gate Valve Equiv to MUDKING style 2", 4"×3", 5"×4” 1

Our valves also can full interchangeable with famous brand MUDKING.

Gate Valve, 2" 5000 PSI Equiv.to MUDKING M1028/M1031/M1025

Gate Valve, 3" 5000 PSI Equiv.to MUDKING M1047/M1056/M1038

Gate Valve, 4" 5000 PSI Equiv.to MUDKING M7420/M17263

Gate Valve, 4" 7500 PSI Equiv.to MUDKING M25051/M25100

We also produce DEMCO DM gate valve parts, major repair kit and minor repair kit, such as STEM SCREW, STEM SCREW SEAL, STEM, SECONDARY SEAL, STEM SEAL ASSEMBLY, BONNET SEAL, GATE, SEAT ASSEMBLY and so on for 2”,3” 4” and 4”x 5” at 2000psi,3000psi, 5000psi

ITEM DESCRIPTION TYPE 2” 4’’×3” 5”×4”
  BASE PART NUMBER WELD M25196 M25051 M25100
1 LUBE FITTING   M5195 M5195 M5195
2 HANDLE   M2139712-01 M2139481-01 M15334
3 STEM TUBE     M7459 M12852
4 STEM CAP     M7411 M15855
5 KEY     M5305-10016
6 STEM SCREW   M1913 M7416 M23888
7 HOUSING SEAL   M5526-224 M5526-226 M5526-228
8 HOUSING   M24982 M7418 M15332
9 STEM 410 SS M24983-107 M24951-107 M2140684-01
10 SECONDARY SEAL HNBR M2712425-13

M2712425-01



M2726268-01


11 PAKING RETAINER   M1940 M7413 M15330
12 STEM SEAL ASSY (CN BRONZE BUSHING) HNBR M23231-008 M1951-008

M15853-008


13 BEARING     M7426
14 GATE CLIP   M450480 M450505 M450505
15 WEAR RING NITRIDE M2269414-01 M452571 M452290
16 BONNET   M24985-030 M17289-029 M2172523-01
17 WEAR RING SEAL VITON M2712425-18

M5521-340



 M5521-349
18 BONNET SEAL HNBR M2712425-60 M2712787-07 M2712426-11
19 GATE NITRIDE 2269412-01 M2171112-01 M2171267-01
20 BODY
21 SEAT HNBR 2269403-01 M2139744-01 M2139746-01
22 COTTER PIN
23 HOUSING STUD   M2066 M2072
24 HOUSING NUT   M2709000-08-01 M2709000-09-01
25 BODY STUD   M15432 M15432 M2171976-11-01
26 BODY NUT   M2709000-10-01 M2709000-10-01 M2709000-11-01

Related Products

Designed for dependable, heavy-duty performance in abrasive service conditions, DEMCO DM gate valves are commonly selected for a number of oilfield applications, including:

  • Drilling standpipe manifold
  • Pump manifold block valves
  • High-pressure mud mixing lines
  • High-pressure drilling system block valves

BETTER Demco DM Type Mud Gate Valve Equiv to MUDKING style 2", 4"×3", 5"×4” 2
